Metal Super Raschig Ring

Time:
2024-02-17 17:58:47
View:
1759

Product Description

Metal super raschig ring, raschig super-ring has a more than 30% greater load capacity, an almost 70% lower pressure drop and a mass transfer efficiency exceeding that of conventional metal packings by over 10%. Metallic super raschig ring, raschig super-ring provides exceptional low pressure drop with high capacities and excellent mass transfer efficiency. Since super raschig ring has been introduced to the maket in 1995, many kinds of mass transfer columns have been packed with raschig ring in various chemical process industrieds, petrochemicals , refinin and environmetal applications.


Super Raschig Ring represents a significant advancement in tower packing technology, building on the legacy of the classic Raschig Ring to enhance the efficiency of mass transfer operations. Tailored for use in a variety of separation processes including distillation, absorption, and scrubbing, these rings are pivotal in sectors such as petrochemicals, chemical processing, and environmental management. Below is a synopsis of the distinctive attributes and benefits of Super Raschig Rings:


Super Raschig Ring Design Characteristics


Enhanced Surface Area: Super Raschig Rings boast a greater surface area relative to their traditional counterparts, facilitating improved efficiency in gas-liquid interactions and mass transfer outcomes.
Refined Geometric Design: Featuring specialized internal structures and apertures, these packings minimize clogging while fostering enhanced mixing and circulation of gas and liquid media.
Superior Gas-Liquid Flow Optimization: The innovative design of Super Raschig Rings is aimed at streamlining the flow dynamics of gas and liquid, minimizing inactive zones, and boosting efficiency and adaptability in operational scenarios.

Advantages in Performance


Superior Mass Transfer Efficiency: The augmented surface area and optimized fluid dynamics contribute to superior mass transfer rates, particularly beneficial in distillation and absorption applications.
Reduced Pressure Drop: Engineered to achieve a minimal pressure drop across the packing, Super Raschig Rings are instrumental in conserving energy and lowering operational expenditures.
Versatile Operational Capability: Capable of performing under a broad spectrum of operational parameters, including diverse pressures and temperatures, these rings are versatile across multiple industrial settings.
Durability Against Corrosion: Available in various materials such as plastics, metals, and ceramics, Super Raschig Rings are designed to withstand corrosive environments, ensuring longevity and reliability.


Specification of raschig super ring

Size

Number

Surface area

Free volume

(inch)

(mm)

(n/m3)

(m2/m3)

(%)

0.6

15

180000

315

0.96

0.8

20

145000

250

0.97

1

25

46500

180

0.98

1.2

30

32000

150

0.98

1.5

38

13750

120

0.98

2

50

9500

100

0.98

3

76

4300

80

0.98



Our advantage:

1.More than 10years manufacturing exper experience.
2.ISO9001:2008 certification available.
3.Reasonale price and good service.
4.Free Sample is available, shipping and taxes paid by buyer.
