Plastic Pentagon Packing

Time:
2020-12-10 06:01:10
View:
1670

Product Description

plastic pentagon packing Ring is on kind type of energy-saving and cost-effective plastic random packings. It's named for its special pentagonal bottom design.Plastic pentagon ring packing has a unique hollow-out structure, speeds up liquid velocity so as to improve Gas & liquid separation efficiency. plastic pentagon packing ring wall's large area opening hole overcomes big area blocking.Five pieces of horizontal bar which bend toward the centers forms more bigger suface for gas & liquid's contacting. More abviously feature is five pieces of downwarded rods evenly distribution. So it is recognized high efficiency random packing used in sepeation.


Plastic pentagon ring has good chemical resistance, high operating efficiency and low investment cost. It is suitable for various absorption, desorption and extraction applications. Plastic pentagon packing ringcan be widely applied in the packing towers in petroleum industry, chemical industry, alkali-Chloride industry, coal gas industry and environmental protection.

Specification of plastic pentagon packing:


Size

Surface area

Void ratio

Bulk density

Number/cbm

mm

m2/m3

%

Kg/cbm

pcs

38*12*1.2

246

95

112

46000

50*17*1.5

218

97

107

21500

76*26*2.5

198

96

92

650

Material: polyethylene (PE), polypropylene (PP), reinforced polypropylene (RPP), polyvinyl chloride (PVC), chloridized polyvinyl chloride (CPVC) and polyvinylidene fluoride (PVDF).
